ICO | Intelligent Channel Optimizer

  • Available in:
  • Asia
  • Australia/New Zealand
  • EMEA
  • Latin America
  • North America

Upstream channel optimization tool for the E6000 and C4/C4c

Contact Us for a Quote
Specifications
Finish making your selections or clear them to view relevant specifications.
Features and Benefits
The Intelligent Channel Optimizer (ICO) is a GUI-based tool used to maximize the throughput of RF upstream channels connected to ARRIS C4 / C4c CMTS DOCSIS® 2.0 (2Dx12U) CAMs, DOCSIS 3.0 (12U and 24U) CAMs, and E6000 CER UCAMs, UCAM-2s and ARRIS E6000n RPD.

After analyzing the noise conditions present for a particular upstream channel, the ICO employs error analysis algorithms to provide guidance on optimal modulation profile and upstream channel settings.

The ICO runs on a laptop or desktop PC and may be used remotely via Telnet, Secure Shell version 2 and SNMP.

Directly measure the noise floor, excluding any transmission (burst) from CM
Capture upstream bursts from a particular CM SID, burst IUC, or logical channel
Maximize the throughput of RF upstream channels
Optimize modulation profiles ICO calculation is done for a wide range of modulation profile types, channel widths, center frequencies and forward error correction (FEC) values
  • Monitors upstream spectrum and analyzes upstream SC-QAM channels
  • Optimize modulation profiles & upstream SC-QAM channel parameters for maximum throughput
  • Works with E6000 CER Release 4.0 or higher, C4 CMTS Release 8.0 or higher and C4c CMTS Release 8.0 or higher
  • Works with ARRIS E6000n RPDs provisioned by the E6000 eCore
  • The ICO analysis is accomplished for a wide range of: Modulation Profile Types, Channel Widths, Center Frequencies, Forward Error Correction (FEC) Values

Product Classification

Regional Availability Asia | Australia/New Zealand | EMEA | Latin America | North America
Product Type CMTS & CCAP software

General Specifications

Hardware Platform Requirements, minimum Network interface with IP connectivity
Major Operation Modes FFT Capture Mode | Optimizer Mode | Theory Mode
Minor Operation Modes Averaging mode | Iterative mode | Worst-case mode
Network Protocol SNMP | SNMP | SSHv2 | SSHv2 | Telnet
Operating System Java 1.5 | Windows 10 | Windows 7 | Windows 8.1
Required CMTS Hardware C4/C4c CMTS with DOCSIS 2.0 CAMs (2D x 12U) | DOCSIS 3.0 CAMs (12U and 24U) | E6000 CER with UCAM, UCAM-2 or ARRIS E6000n RPD
Required CMTS Software C4 Release 8.0 or higher | C4c Release 8.0 or higher | E6000 Release 4.0 or higher | E6000n RPD Release 1.0 or higher provisioned by the E6000
Resolution Requirements, minimum 1024 x 768
