CS-5G-MP

LazrSPEED® OM5 WideBand Multimode Fiber
Specifications
Finish making your selections or clear them to view relevant specifications.
How to Buy
Specifications

Product Classification

Portfolio CommScope®
Product Type Optical fiber

General Specifications

Cladding Diameter 125 µm
Cladding Diameter Tolerance ±0.8 µm
Cladding Non-Circularity, maximum 0.7 %
Coating Diameter (Colored) 254 µm
Coating Diameter (Uncolored) 242 µm
Coating Diameter Tolerance (Colored) ±7 µm
Coating Diameter Tolerance (Uncolored) ±5 µm
Coating/Cladding Concentricity Error, maximum 12 µm
Core Diameter 50 µm
Core Diameter Tolerance ±2.5 µm
Core/Clad Offset, maximum 1 µm
Proof Test 689.476 N/mm² | 100000 psi

Mechanical Specifications

Macrobending, 15 mm mandrel, 2 turns 0.30 dB @ 1,300 nm | 0.10 dB @ 850 nm
Macrobending, 7.5 mm mandrel, 2 turns 0.50 dB @ 1,300 nm | 0.20 dB @ 850 nm
Coating Strip Force, maximum 4.5 N | 1.012 lbf
Coating Strip Force, minimum 0.9 N | 0.202 lbf
Dynamic Fatigue Parameter, minimum 18

Optical Specifications

Numerical Aperture 0.20000000298023224
Numerical Aperture Tolerance ±0.010
Point Defects, maximum 0.15 dB
Zero Dispersion Slope, maximum (OM5) -412/(840(1-(λ0/840)^4)) ps/[km-nm-nm]
Zero Dispersion Wavelength, maximum 1328 nm
Zero Dispersion Wavelength, minimum 1297 nm

Optical Specifications, Wavelength Specific

1 Gbps Ethernet Distance 1,110 m @ 850 nm | 600 m @ 1,300 nm
10 Gbps Ethernet Distance 550 m @ 850 nm
Attenuation, maximum 1.00 dB/km @ 1,300 nm | 2.20 dB/km @ 953 nm | 3.00 dB/km @ 850 nm
Bandwidth, Laser, minimum 500 MHz-km @ 1,300 nm | 2,600 MHz-km @ 953 nm | 4,700 MHz-km @ 850 nm
Bandwidth, OFL, minimum 500 MHz-km @ 1,300 nm | 3,500 MHz-km @ 850 nm | 1,950 MHz-km @ 953 nm
Index of Refraction 1.478 @ 1,300 nm | 1.483 @ 850 nm
Standards Compliance IEC 60793-2-10, edition 6, model A1a.4 | TIA-492AAAE (OM5) | ANSI/TIA-568.3-D wideband multimode fiber cable | ISO 11801-1 cabled optical fiber performance category OM5

Environmental Specifications

Heat Aging, maximum 0.10 dB/km @ 85 °C
Temperature Dependence, maximum 0.1 dB/km
Temperature Humidity Cycling, maximum 0.1 dB/km
Water Immersion, maximum 0.10 dB/km @ 23 °C

Regulatory Compliance/Certifications

Agency Classification
ISO 9001:2015 Designed, manufactured and/or distributed under this quality management system
