UGBKIT-T

Base Product: GROUNDING-BUSS-SERIES

Tinned Copper Ground Buss Bar, 1/4 in x 2-1/2 in x 19-1/2 in (6.4 mm x 63.5 mm x 495.3 mm)

Find a Partner
Specifications
Finish making your selections or clear them to view relevant specifications.

Product Classification

Product Type Grounding bar
Ordering Note CommScope® non-standard product

Dimensions

Height 63.5 mm | 2.5 in
Length 495.3 mm | 19.5 in
Material Thickness 6.35 mm | 0.25 in
Hole Size 7/16 in
Hole Distance, center to center 35.052 mm | 1.38 in

Material Specifications

Material Type Tinned copper

Packaging and Weights

Height, packed 668.02 mm | 26.3 in
Width, packed 71.12 mm | 2.8 in
Length, packed 68.58 mm | 2.7 in
Included Galvanized angle adapter | Grounding bar | Insulators | Mounting brackets | Universal hardware
Packaging quantity 1
Weight, gross 2.01 kg | 4.431 lb

Regulatory Compliance/Certifications

Agency Classification
ISO 9001:2015 Designed, manufactured and/or distributed under this quality management system
ROHS Compliant
CHINA-ROHS Below maximum concentration value
REACH-SVHC Compliant as per SVHC revision on www.commscope.com/ProductCompliance
UK-ROHS Compliant
