Small Cell Antennas

of 18 results found
View:

Filters

3X-V65S-C3-3XR 3X-V65S-C3-3XR
6-port small cell antenna, 6x 1695–2690 MHz, 65° HPBW, 3x RET.
3X-V65S-C3-3XR
  • Operating Frequency Band: 1695 – 2690 MHz
  • Horizontal Beamwidth: 65 °
  • Length: 596 mm | 23.465 in
  • Outer Diameter: 200 mm | 7.874 in
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 6
  • RF Connector Quantity, high band: 6
3X-V65S-C3-3XR
  • Operating Frequency Band: 1695 – 2690 MHz
  • Horizontal Beamwidth: 65 °
  • Length: 596 mm | 23.465 in
  • Outer Diameter: 200 mm | 7.874 in
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 6
  • RF Connector Quantity, high band: 6
DB992HG28N-B DB992HG28N-B
1-port small cell antenna, 1710–2490 MHz, 30° HPBW, fixed electrical tilt
DB992HG28N-B
  • Operating Frequency Band: 1710 – 2490 MHz
  • Horizontal Beamwidth: 30 °
  • Length: 311 mm | 12.244 in
  • Width: 311 mm | 12.244 in
  • RF Connector Interface: N Female
  • RF Connector Quantity, total: 1
  • RF Connector Quantity, high band: 1
DB992HG28N-B
  • Operating Frequency Band: 1710 – 2490 MHz
  • Horizontal Beamwidth: 30 °
  • Length: 311 mm | 12.244 in
  • Width: 311 mm | 12.244 in
  • RF Connector Interface: N Female
  • RF Connector Quantity, total: 1
  • RF Connector Quantity, high band: 1
NH180QS-DG-F0M NH180QS-DG-F0M
2-port small cell antenna, 2x (698-896 and 1710–2180 MHz), 180° HPBW with fixed tilt in the low band and manual tilt in the high band. Contains internal diplexer and active GPS L1 band antenna
NH180QS-DG-F0M
  • Operating Frequency Band: 1710 – 2180 MHz | 698 – 896 MHz
  • Horizontal Beamwidth: 180 °
  • Length: 728 mm | 28.661 in
  • Outer Diameter: 305 mm | 12.008 in
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 2
NH180QS-DG-F0M
  • Operating Frequency Band: 1710 – 2180 MHz | 698 – 896 MHz
  • Horizontal Beamwidth: 180 °
  • Length: 728 mm | 28.661 in
  • Outer Diameter: 305 mm | 12.008 in
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 2
NH360QS-DG-F0M NH360QS-DG-F0M
2-port small cell antenna, 2x (698-896 and 1710–2180 MHz), 360° HPBW with fixed tilt in the low band and manual tilt in the high band. Contains internal diplexer and active GPS L1 band antenna
NH360QS-DG-F0M
  • Operating Frequency Band: 698 – 896 MHz | 1710 – 2180 MHz
  • Horizontal Beamwidth: 360 °
  • Length: 728 mm | 28.661 in
  • Outer Diameter: 305 mm | 12.008 in
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 2
NH360QS-DG-F0M
  • Operating Frequency Band: 698 – 896 MHz | 1710 – 2180 MHz
  • Horizontal Beamwidth: 360 °
  • Length: 728 mm | 28.661 in
  • Outer Diameter: 305 mm | 12.008 in
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 2
NH360QS-F0M NH360QS-F0M
4-port small cell antenna, 2x 698-896 and 2x 1710–2180 MHz, 360° HPBW with fixed tilt in the low band and manual tilt in the high band.
NH360QS-F0M
  • Operating Frequency Band: 1710 – 2180 MHz | 698 – 896 MHz
  • Horizontal Beamwidth: 360 °
  • Length: 728 mm | 28.661 in
  • Outer Diameter: 305 mm | 12.008 in
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, high band: 2
  • RF Connector Quantity, low band: 2
NH360QS-F0M
  • Operating Frequency Band: 1710 – 2180 MHz | 698 – 896 MHz
  • Horizontal Beamwidth: 360 °
  • Length: 728 mm | 28.661 in
  • Outer Diameter: 305 mm | 12.008 in
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, high band: 2
  • RF Connector Quantity, low band: 2
NH65PS-DG-F0M NH65PS-DG-F0M
2-port small cell antenna, 2x (698-896 and 1710–2180 MHz), 65° HPBW (bi-directional) with fixed tilt in the low band and manual tilt in the high band. Contains internal diplexer and GPS antenna.
NH65PS-DG-F0M
  • Operating Frequency Band: 698 – 896 MHz | 1710 – 2180 MHz
  • Horizontal Beamwidth: 65 °
  • Length: 728 mm | 28.661 in
  • Outer Diameter: 305 mm | 12.008 in
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 2
NH65PS-DG-F0M
  • Operating Frequency Band: 698 – 896 MHz | 1710 – 2180 MHz
  • Horizontal Beamwidth: 65 °
  • Length: 728 mm | 28.661 in
  • Outer Diameter: 305 mm | 12.008 in
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 2
NH65S-DG-F0M NH65S-DG-F0M
2-port small cell antenna, 2x (698-896 and 1710–2180 MHz), 65° HPBW with fixed tilt in the low band and manual tilt in the high band. Contains internal diplexer and active GPS L1 band antenna.
NH65S-DG-F0M
  • Operating Frequency Band: 1710 – 2180 MHz | 698 – 896 MHz
  • Horizontal Beamwidth: 65 °
  • Length: 728 mm | 28.661 in
  • Width: 301 mm | 11.85 in
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 2
NH65S-DG-F0M
  • Operating Frequency Band: 1710 – 2180 MHz | 698 – 896 MHz
  • Horizontal Beamwidth: 65 °
  • Length: 728 mm | 28.661 in
  • Width: 301 mm | 11.85 in
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 2
NH65T-DG-F0 NH65T-DG-F0
2-port small cell antenna, 2x (698-896 and 1710–2180 MHz), 65° HPBW, fixed electrical tilt, with internal diplexer and active GPS L1 band antenna.
NH65T-DG-F0
  • Operating Frequency Band: 698 – 896 MHz | 1710 – 2180 MHz
  • Horizontal Beamwidth: 65 °
  • Length: 389 mm | 15.315 in
  • Width: 301 mm | 11.85 in
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 2
NH65T-DG-F0
  • Operating Frequency Band: 698 – 896 MHz | 1710 – 2180 MHz
  • Horizontal Beamwidth: 65 °
  • Length: 389 mm | 15.315 in
  • Width: 301 mm | 11.85 in
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 2
NNV4SSP-360S-F4 NNV4SSP-360S-F4
18-port small cell antenna, 4x 698-896, 8x 1695–2690, 4x 3400-3800 and 2x 5150-5925 MHz, 360° Horizontal Beamwidth, fixed tilt.
NNV4SSP-360S-F4
  • Operating Frequency Band: 1695 – 2690 MHz | 5150 – 5925 MHz | 698 – 894 MHz | 3300 – 3800 MHz
  • Horizontal Beamwidth: 360 °
  • Length: 680 mm | 26.772 in
  • Outer Diameter: 370 mm | 14.567 in
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 18
  • RF Connector Quantity, high band: 14
  • RF Connector Quantity, low band: 4
NNV4SSP-360S-F4
  • Operating Frequency Band: 1695 – 2690 MHz | 5150 – 5925 MHz | 698 – 894 MHz | 3300 – 3800 MHz
  • Horizontal Beamwidth: 360 °
  • Length: 680 mm | 26.772 in
  • Outer Diameter: 370 mm | 14.567 in
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 18
  • RF Connector Quantity, high band: 14
  • RF Connector Quantity, low band: 4
NNVVSSP-360S-FM NNVVSSP-360S-FM
14-port quasi-omni antenna, 4x 698–896, 4x 1695–2690, 4x 3400-3800 and 2x 5150-5925 MHz, 360° horizontal beamwidth. Fixed and manual tilt.
NNVVSSP-360S-FM
  • Operating Frequency Band: 3400 – 3800 MHz | 1695 – 2690 MHz | 698 – 896 MHz | 5150 – 5925 MHz
  • Horizontal Beamwidth: 360 °
  • Length: 730 mm | 28.74 in
  • Outer Diameter: 305 mm | 12.008 in
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 14
  • RF Connector Quantity, high band: 10
  • RF Connector Quantity, low band: 4
NNVVSSP-360S-FM
  • Operating Frequency Band: 3400 – 3800 MHz | 1695 – 2690 MHz | 698 – 896 MHz | 5150 – 5925 MHz
  • Horizontal Beamwidth: 360 °
  • Length: 730 mm | 28.74 in
  • Outer Diameter: 305 mm | 12.008 in
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 14
  • RF Connector Quantity, high band: 10
  • RF Connector Quantity, low band: 4
QD-2402 QD-2402
1-port small cell antenna, 2400–2500 MHz, 27° HPBW, fixed electrical tilt
QD-2402
  • Operating Frequency Band: 2400 – 2500 MHz
  • Horizontal Beamwidth: 27 °
  • Length: 280 mm | 11.024 in
  • Width: 272 mm | 10.709 in
  • RF Connector Interface: N Female
  • RF Connector Quantity, total: 1
  • RF Connector Quantity, high band: 1
QD-2402
  • Operating Frequency Band: 2400 – 2500 MHz
  • Horizontal Beamwidth: 27 °
  • Length: 280 mm | 11.024 in
  • Width: 272 mm | 10.709 in
  • RF Connector Interface: N Female
  • RF Connector Quantity, total: 1
  • RF Connector Quantity, high band: 1
V360QS-C3-3XR V360QS-C3-3XR
2-port small cell antenna, 2x 1695–2690 MHz, 360° HPBW, 3x RET
V360QS-C3-3XR
  • Operating Frequency Band: 1695 – 2690 MHz
  • Horizontal Beamwidth: 360 °
  • Length: 596 mm | 23.465 in
  • Outer Diameter: 200 mm | 7.874 in
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 2
  • RF Connector Quantity, high band: 2
V360QS-C3-3XR
  • Operating Frequency Band: 1695 – 2690 MHz
  • Horizontal Beamwidth: 360 °
  • Length: 596 mm | 23.465 in
  • Outer Diameter: 200 mm | 7.874 in
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 2
  • RF Connector Quantity, high band: 2
