CS-6F-TB

OptiSPEED® OM1 Multimode Fiber
Specifications
Finish making your selections or clear them to view relevant specifications.
How to Buy
Specifications

Product Classification

Portfolio CommScope®
Product Type Optical fiber

General Specifications

Cladding Diameter 125 µm
Cladding Diameter Tolerance ±1.0 µm
Cladding Non-Circularity, maximum 1 %
Coating Diameter (Colored) 254 µm
Coating Diameter (Uncolored) 245 µm
Coating Diameter Tolerance (Colored) ±7 µm
Coating Diameter Tolerance (Uncolored) ±10 µm
Coating/Cladding Concentricity Error, maximum 12 µm
Core Diameter 62.5 µm
Core Diameter Tolerance ±2.5 µm
Core/Clad Offset, maximum 1 µm
Proof Test 689.476 N/mm² | 100000 psi
Tight Buffer Diameter 900 µm
Tight Buffer Diameter Tolerance ±40 µm

Mechanical Specifications

Macrobending, 75 mm mandrel, 100 turns 0.50 dB @ 1,300 nm | 0.50 dB @ 850 nm
Coating Strip Force, maximum 8.9 N | 2.001 lbf
Coating Strip Force, minimum 1.3 N | 0.292 lbf
Dynamic Fatigue Parameter, minimum 18

Optical Specifications

Numerical Aperture 0.2750000059604645
Numerical Aperture Tolerance ±0.015
Point Defects, maximum 0.15 dB
Zero Dispersion Slope, maximum 0.097 ps/[km-nm-nm]
Zero Dispersion Wavelength, maximum 1365 nm
Zero Dispersion Wavelength, minimum 1320 nm

Optical Specifications, Wavelength Specific

1 Gbps Ethernet Distance 300 m @ 850 nm | 550 m @ 1,300 nm
Attenuation, maximum 3.00 dB/km @ 850 nm | 1.00 dB/km @ 1,300 nm
Backscatter Coefficient -75.7 dB @ 1,300 nm | -68.0 dB @ 850 nm
Bandwidth, OFL, minimum 500 MHz-km @ 1,300 nm | 220 MHz-km @ 850 nm
Index of Refraction 1.491 @ 1,300 nm | 1.496 @ 850 nm
Standards Compliance TIA-492AAAA (OM1)

Environmental Specifications

Heat Aging, maximum 0.20 dB/km @ 85 °C
Temperature Dependence, maximum 0.1 dB/km
Temperature Humidity Cycling, maximum 0.2 dB/km
Water Immersion, maximum 0.20 dB/km @ 23 °C

Regulatory Compliance/Certifications

Agency Classification
ISO 9001:2015 Designed, manufactured and/or distributed under this quality management system

Product Classification

Portfolio CommScope®
Product Type Optical fiber

General Specifications

Cladding Diameter 125 µm
Cladding Diameter Tolerance ±1.0 µm
Cladding Non-Circularity, maximum 1 %
Coating Diameter (Colored) 254 µm
Coating Diameter (Uncolored) 245 µm
Coating Diameter Tolerance (Colored) ±7 µm
Coating Diameter Tolerance (Uncolored) ±10 µm
Coating/Cladding Concentricity Error, maximum 12 µm
Core Diameter 62.5 µm
Core Diameter Tolerance ±2.5 µm
Core/Clad Offset, maximum 1 µm
Proof Test 689.476 N/mm² | 100000 psi
Tight Buffer Diameter 900 µm
Tight Buffer Diameter Tolerance ±40 µm

Mechanical Specifications

Macrobending, 75 mm mandrel, 100 turns 0.50 dB @ 1,300 nm | 0.50 dB @ 850 nm
Coating Strip Force, maximum 8.9 N | 2.001 lbf
Coating Strip Force, minimum 1.3 N | 0.292 lbf
Dynamic Fatigue Parameter, minimum 18

Optical Specifications

Numerical Aperture 0.2750000059604645
Numerical Aperture Tolerance ±0.015
Point Defects, maximum 0.15 dB
Zero Dispersion Slope, maximum 0.097 ps/[km-nm-nm]
Zero Dispersion Wavelength, maximum 1365 nm
Zero Dispersion Wavelength, minimum 1320 nm

Optical Specifications, Wavelength Specific

1 Gbps Ethernet Distance 300 m @ 850 nm | 550 m @ 1,300 nm
Attenuation, maximum 3.00 dB/km @ 850 nm | 1.00 dB/km @ 1,300 nm
Backscatter Coefficient -75.7 dB @ 1,300 nm | -68.0 dB @ 850 nm
Bandwidth, OFL, minimum 500 MHz-km @ 1,300 nm | 220 MHz-km @ 850 nm
Index of Refraction 1.491 @ 1,300 nm | 1.496 @ 850 nm
Standards Compliance TIA-492AAAA (OM1)

Environmental Specifications

Heat Aging, maximum 0.20 dB/km @ 85 °C
Temperature Dependence, maximum 0.1 dB/km
Temperature Humidity Cycling, maximum 0.2 dB/km
Water Immersion, maximum 0.20 dB/km @ 23 °C

Regulatory Compliance/Certifications

Agency Classification
ISO 9001:2015 Designed, manufactured and/or distributed under this quality management system
