WB-CS24-3

Safety Grated Channel Support, 24 in wide for 3-1/2 in OD pipe
Specifications
Finish making your selections or clear them to view relevant specifications.
How to Buy
Specifications

Product Classification

Product Type Support bracket

General Specifications

Application Waveguide bridge kit, 24 in
Mounting Pipe, 88.9 mm (3-1/2 in) OD

Dimensions

Height 4 in | 101.6 mm
Width 32 in | 812.8 mm
Length 4 in | 101.6 mm

Material Specifications

Material Type Hot dip galvanized steel

Packaging and Weights

Included Hardware | Channel support bracket
Packaging quantity 1
Weight, net 8.2 kg | 18.078 lb

Outline Drawing

Click on image to enlarge.

Regulatory Compliance/Certifications

Agency Classification
ISO 9001:2015 ISO 9001:2015Designed, manufactured and/or distributed under this quality management system
ROHS ROHSCompliant
CHINA-ROHS CHINA-ROHSBelow maximum concentration value
REACH-SVHC REACH-SVHCCompliant as per SVHC revision on www.commscope.com/ProductCompliance

Product Classification

Product Type Support bracket

General Specifications

Application Waveguide bridge kit, 24 in
Mounting Pipe, 88.9 mm (3-1/2 in) OD

Dimensions

Height 4 in | 101.6 mm
Width 32 in | 812.8 mm
Length 4 in | 101.6 mm

Material Specifications

Material Type Hot dip galvanized steel

Packaging and Weights

Included Hardware | Channel support bracket
Packaging quantity 1
Weight, net 8.2 kg | 18.078 lb
Click on image to enlarge.

Regulatory Compliance/Certifications

Agency Classification
ISO 9001:2015 ISO 9001:2015Designed, manufactured and/or distributed under this quality management system
ROHS ROHSCompliant
CHINA-ROHS CHINA-ROHSBelow maximum concentration value
REACH-SVHC REACH-SVHCCompliant as per SVHC revision on www.commscope.com/ProductCompliance
