D80635-000 | GSIC-1/2-ANT-L-00-INT01

GSIC Weatherproofing Gel Sealed Antenna Transition Boot, 1/2 inch cable, large

Find a Partner

Specifications

Finish making your selections or clear them to view relevant specifications.

Download

Features and Benefits

Gel-sealed weatherproofing boots for sealing coaxial cable connection points providing an efficient moisture block
Wraparound design eliminates the need to disconnect the connectors before installation
No tape, no mastics or tools required for installation and removal

Specifications

Product Classification

Application	½” Jumper to DIN connector
Color	Black

Length	117 mm \| 4.606 in
Cable Diameter for Seal, maximum	17 mm \| 0.669 in
Cable Diameter for Seal, minimum	13 mm \| 0.512 in
Inner Diameter	26 mm \| 1.024 in

Material Type

Engineered plastic

Operating Temperature	-40 °C to +70 °C (-40 °F to +158 °F)
Weatherproofing Method	IP68

Packaging quantity

Agency	Classification
ROHS	Compliant
CHINA-ROHS	Below maximum concentration value
REACH-SVHC	Compliant as per SVHC revision on www.commscope.com/ProductCompliance
UK-ROHS	Compliant
